CFM-7025C-240-394
24 V, 0.14 A, 70 x 70 x 25 mm, Dc Fan
Thanks to the innovative omniCOOL™ system that provides improved performance and longer operational life, this axial fan bridges the cost-performance gap between conventional sleeve and ball bearing fan designs.
Features
| omniCOOL™ bearing system |
| 70 x 70 mm frame |
| Multiple speed options for different cooling needs |
| Tachometer signal available |
| Auto restart protection standard on all models |
Specifications
| Type | Description | |
|---|---|---|
| Air Flow (CFM) | 34.5 |
|
| Bearing Type | omniCOOL™ |
|
| Rated Speed (RPM) | 4000 |
|
| Static Pressure (inH2O) | 0.22 |
|
| Noise (dBA) | 37.1 |
|
| Rated Voltage (Vdc) | 24 |
|
| Max Input Current (mA) | 140 |
|
| Tachometer Signal | No |
|
| Rotation Detector | No |
|
| PWM Control Signal | No |
|
| Dimensions LxWxH (mm) | 70 x 70 x 25 |
|
| Operating Temp Range (°C) | -10 ~ 70 |
|
| Series | CFM-70C |
|
