Features
| Sleeve bearing construction |
| 60 x 60 mm frame |
| Multiple speed options for different cooling needs |
| Tachometer signal available |
| Auto restart protection standard on all models |
Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | Sleeve |
|
| Air Flow (CFM) | 11.43 |
|
| Rated Speed (RPM) | 3000 |
|
| Static Pressure (inH2O) | 0.06 |
|
| Noise (dBA) | 25.7 |
|
| Rated Voltage (Vdc) | 12 |
|
| Max Input Current (mA) | 80 |
|
| Tachometer Signal | Yes |
|
| Rotation Detector | No |
|
| PWM Control Signal | No |
|
| Dimensions LxWxH (mm) | 60 x 60 x 20 |
|
| Operating Temp Range (°C) | -10 ~ 70 |
|
| Series | CFM-60S |
|
