CFM-5015CF-130-224-22
12 V, 0.06 A, 50 x 50 x 15 mm, Dc Fan, Tachometer Signal, PWM Control Signal
The CFM-50CF series is a family of 50 x 50 mm dc axial fans featuring airflows up to 15.57 CFM and rated speeds from 3000 to 6000 RPM. Thanks to the innovative omniCOOL™ system that provides improved performance and longer operational life, these axial fans bridge the cost-performance gap between conventional sleeve and ball bearing fan designs.
Features
| omniCOOL™ bearing system |
| 50 x 50 mm frame |
| Multiple speed options for different cooling needs |
| Tachometer signal available |
Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | omniCOOL™ |
|
| Max Input Current (mA) | 60 |
|
| Dimensions LxWxH (mm) | 50 x 50 x 15 |
|
| Operating Temp Range (°C) | -10 ~ 70 |
|
| Series | CFM-50CF |
|
| Air Flow (CFM) | 7.8 |
|
| Noise (dBA) | 22.4 |
|
| PWM Control Signal | Yes |
|
| Rated Speed (RPM) | 3000 |
|
| Rated Voltage (Vdc) | 12 |
|
| Rotation Detector | No |
|
| Static Pressure (inH2O) | 0.05 |
|
| Tachometer Signal | Yes |
|
