CFM-4010C-165-251-22
12 V, 60 mA, 40 x 40 x 10 mm, Dc Fan, Tachometer Signal, PWM Control Signal
The CFM-40C series is a family of 40 x 40 mm dc axial fans featuring airflows up to 6.76 CFM and rated speeds from 5000 to 8000 RPM. Thanks to the innovative omniCOOL™ system that provides improved performance and longer operational life, these axial fans bridge the cost-performance gap between conventional sleeve and ball bearing fan designs.
Features
| omniCOOL™ bearing system |
| 40 x 40 mm frame |
| Multiple speed options for different cooling needs |
| Tachometer signal available |
Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | omniCOOL™ |
|
| Max Input Current (mA) | 60 |
|
| Dimensions LxWxH (mm) | 40 x 40 x 10 |
|
| Series | CFM-40C |
|
| Air Flow (CFM) | 5.49 |
|
| Noise (dBA) | 25.1 |
|
| PWM Control Signal | Yes |
|
| Rated Speed (RPM) | 6500 |
|
| Rated Voltage (Vdc) | 12 |
|
| Rotation Detector | No |
|
| Static Pressure (inH2O) | 0.11 |
|
| Tachometer Signal | Yes |
|
