Specifications
| Type | Description | |
|---|---|---|
| Fan Type | Axial Fan |
|
| Bearing Type | Ball |
|
| Air Flow at 50Hz (CFM) | 162.04 |
|
| Air Flow at 60Hz (CFM) | 140.81 |
|
| Rated Speed at 50Hz (RPM) | 2400 |
|
| Rated Speed at 60Hz (RPM) | 2200 |
|
| Static Pressure at 50Hz (inH2O) | 0.41 |
|
| Static Pressure at 60Hz (inH2O) | 0.17 |
|
| Noise at 50Hz (dBA) | 51.3 |
|
| Noise at 60Hz (dBA) | 49 |
|
| Rated Voltage (Vac) | 220 |
|
| Operating Voltage (Vdc) | 220 ~ 240 |
|
| Rated Current at 50Hz (mA) | 200 |
|
| Rated Current at 60Hz (mA) | 200 |
|
| Rated Power at 60Hz (W) | 28.1 |
|
| Rated Power at 50Hz (W) | 28 |
|
| Max Input Current (mA) | 230 |
|
| Tachometer Signal | No |
|
| Rotation Detector | No |
|
| PWM Control Signal | No |
|
| Dimensions LxWxH (mm) | 172 x 150 x 51 |
|
| Dimensions LxWxH (in) | 6.77 x 5.91 x 2.01 |
|
| Operating Temp Range (°C) | -10 ~ 70 |
|
| Series | CAF-A7B |
|
