Specifications
| Type | Description | |
|---|---|---|
| Coil Voltage (V) | 12 |
|
| Nominal Coil Power (mW) | 400 |
|
| Contact Form | SPDT (1 Form C) |
|
| Contact Rating | 8 A @ 250 VAC/30 VDC |
|
| Contact Resistance (mΩ) | 100 |
|
| Max Switching Voltage (VAC) | 440 |
|
| Max Switching Voltage (VDC) | 120 |
|
| Max Switching Current (A) | 16 |
|
| Seal Rating | Flux |
|
| Coil Insulation Class | B |
|
| Mounting Style | Through Hole |
|
| Termination | Pc Pins |
|
| Contact Material | Ag Alloy |
|
| Dimensions LxWxH (mm) | 29 x 12.6 x 15.8 |
|
| Series | PR22 |
|
