Specifications
| Type | Description | |
|---|---|---|
| Connector Type | Push-In Spring |
|
| Termination Style | Feed Through |
|
| IEC Current Rating (A) | 24 |
|
| Insulation Resistance (MΩ at 500 Vdc) | 500 |
|
| UL Current Rating (A) | 20 |
|
| Frequency (V) | 3000 |
|
| IEC Voltage Rating (Vdc) | 800 |
|
| UL Voltage Rating (Vdc) | 600 |
|
| Surge Voltage (V) | 6000 |
|
| Voltage Drop (mV) | 3.2 |
|
| Wire Gauge (AWG) | 26~12 |
|
| Stripping Length (mm) | 10~12 |
|
| Number of Positions | 4 |
|
| Material | UL94 V-0 |
|
| Wire Size (mm²) | 2.5 |
|
| Operating Temp Range (°C) | -40 ~ 105 |
|
