Specifications
| Type | Description | |
|---|---|---|
| Terminal Type | PC Pin |
|
| Termination | Press-Fit |
|
| Length Above Flange (mm) | 1.51 |
|
| Length Overall (mm) | 2.26 |
|
| Mounting Hole Diameter (mm) | 2.4 |
|
| Pin Size Above Flange (mm) | 1.82 |
|
| Flange Diameter (mm) | 2.2 |
|
| Contact Finish Thickness (µin) | 20 |
|
| Contact Finish Thickness (µm) | 0.51 |
|
| Contact Material | Brass Alloy |
|
| Terminal Style | Single End |
|
| Contact Finish | Gold Plated |
|
