SD7-2-B
SD 4.0 Card Connectors, 21 Positions, Connector, Push In, Pull Out, Surface Mount, 3.9 mm Height Above Board, Gold Flash
Specifications
| Type | Description | |
|---|---|---|
| Connector Type | Connector |
|
| Compatible Card | SD 4.0 Card, SD 7.0 Card |
|
| Mounting Style | Surface Mount |
|
| Removal Method | Push In, Pull Out |
|
| Number of Positions | 21 |
|
| Contact Finish | Gold Plated |
|
| Height Above Board (mm) | 3.9 |
|
| Card Detect Switch | Yes |
|
| Contact Finish Thickness | Gold Flash |
|
