PPM-2-35135-SG-WT
PPM-2-35135-SG-WT Alternate Variation

PPM-2-35135-SG-WT

1.35 x 3.5 mm, Overmold, Dc Power Plug Connector

Datasheet

Specifications

Type Description
Select
Connector Type Plug
Inner Diameter (mm) 1.35
Outer Diameter (mm) 3.5
Insertion Depth/Length (mm) 11.6
Mounting Style Cable - Overmold
Orientation Vertical
Voltage Rating (Vdc) 20
Current Rating (A) 4
Number of Conductors 2
Internal Switch(es) 0
Shielding No

Technical Docs

Datasheet 3D Model
