Specifications
| Type | Description | |
|---|---|---|
| Connector Type | Jack |
|
| Inner Diameter (mm) | 2.5 |
|
| Outer Diameter (mm) | 5.9 |
|
| Insertion Depth/Length (mm) | 8.2 |
|
| Mounting Style | Through Hole |
|
| Orientation | Horizontal |
|
| Voltage Rating (Vdc) | 24 |
|
| Current Rating (A) | 5 |
|
| Number of Conductors | 3 |
|
| Internal Switch(es) | 1 |
|
| Shielding | Yes |
|
| Dimensions LxWxH (mm) | 11.5 x 10.9 x 7.2 |
|
