CFM-9225V-239-420-20
Recommended Replacement
CFM-9225V-230-340-20
24 V, 87 mA, 92 x 92 x 25 mm, Dc Fan, Tachometer Signal
24 V, 178 mA, 92 x 92 x 25 mm, Dc Fan, Tachometer Signal
Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | omniCOOL™ |
|
| Air Flow (CFM) | 65 |
|
| Rated Speed (RPM) | 3900 |
|
| Static Pressure (inH2O) | 0.25 |
|
| Noise (dBA) | 42 |
|
| Rated Voltage (Vdc) | 24 |
|
| Max Input Current (mA) | 178 |
|
| Tachometer Signal | Yes |
|
| Rotation Detector | No |
|
| PWM Control Signal | No |
|
| Dimensions LxWxH (mm) | 92 x 92 x 25 |
|
| Operating Temp Range (°C) | -10 ~ 70 |
|
