CFM-8015V-230-347
Recommended Replacement
CFM-8015BF-230-301
24 V, 0.21 A, 80 x 80 x 15 mm, Dc Fan
CFM-8015CF-230-301
24 V, 0.21 A, 80 x 80 x 15 mm, Dc Fan
24 V, 106 mA, 80 x 80 x 15 mm, Dc Fan
Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | omniCOOL™ |
|
| Air Flow (CFM) | 37 |
|
| Rated Speed (RPM) | 3000 |
|
| Static Pressure (inH2O) | 0.14 |
|
| Noise (dBA) | 34.7 |
|
| Rated Voltage (Vdc) | 24 |
|
| Max Input Current (mA) | 106 |
|
| Tachometer Signal | No |
|
| Rotation Detector | No |
|
| PWM Control Signal | No |
|
| Dimensions LxWxH (mm) | 80 x 80 x 15 |
|
| Series | CFM-80V |
|
