CFM-6015-13-22
12 V, 0.17 A, 60 x 60 x 15.4 mm, Dc Fan, Tachometer Signal, PWM Control Signal
Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | Ball |
|
| Air Flow (CFM) | 27.5 |
|
| Rated Speed (RPM) | 5100 |
|
| Static Pressure (inH2O) | 0.23 |
|
| Noise (dBA) | 39 |
|
| Rated Voltage (Vdc) | 12 |
|
| Max Input Current (mA) | 220 |
|
| Tachometer Signal | Yes |
|
| Rotation Detector | No |
|
| PWM Control Signal | Yes |
|
| Dimensions LxWxH (mm) | 60 x 60 x 15.4 |
|
| Operating Temp Range (°C) | -10 ~ 70 |
|
