Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | omniCOOL™ |
|
| Air Flow (CFM) | 13 |
|
| Rated Speed (RPM) | 5000 |
|
| Static Pressure (inH2O) | 0.17 |
|
| Noise (dBA) | 29 |
|
| Rated Voltage (Vdc) | 24 |
|
| Max Input Current (mA) | 34 |
|
| Tachometer Signal | No |
|
| Rotation Detector | Yes |
|
| PWM Control Signal | No |
|
| Dimensions LxWxH (mm) | 50 x 50 x 15 |
|
| Operating Temp Range (°C) | -10 ~ 70 |
|
| Series | CFM-50V |
|
