Specifications
| Type | Description | |
|---|---|---|
| Coil Voltage (V) | 24 |
|
| Nominal Coil Power (mW) | 900 |
|
| Contact Form | SPST (1 Form A) |
|
| Contact Rating | 30 A @ 250 VAC/24 VDC |
|
| Contact Resistance (mΩ) | 100 |
|
| Max Switching Voltage (VAC) | 250 |
|
| Max Switching Voltage (VDC) | 28 |
|
| Max Switching Current (A) | 30 |
|
| Seal Rating | Flux |
|
| Coil Insulation Class | B |
|
| Mounting Style | Through Hole |
|
| Termination | Pc Pins |
|
| Contact Material | Ag Alloy |
|
| Dimensions LxWxH (mm) | 27.4 x 31.8 x 20 |
|
| Series | PR23 |
|
